Wire Pulling Rope | Cable

Wire Pulling Rope | Cable
Pinch To Zoom

Wire Pulling Rope | Cable

Diameter
Length

Total:

$109.99

U.S. orders ship today if ordered in 4 hr 10 mins.
We also ship overseas! Cost calculated in cart.

Videos

Wire Pulling Rope | Double Braid Rope for Pulling Wire

In this video Phil gives a detailed explanation of the Cable P...

Wire Pulling Rope | Double Braid Rope for Pulling Wire Play Video: Wire Pulling Rope | Double Braid Rope for Pulling Wire

Wire Pulling Rope | Double Braid Rope for Pulling Wire

Product Details

Highlights
  • Premium Polyester
  • Highest strength
  • Made in USA
  • Spliced, stitched eyes
  • Heavy-duty wooden reels
Description

Our premium, high-tenacity, double braid cable pulling ropes are manufactured in the USA and are made to be used on high strength cable pullers and winches. Our pull ropes can be used with your puller or tugger made by Porta-pull, Greenlee, Gardner Bender, Southwire, Ensley, itoolco, etc. These pulling ropes are also designed to be used for pulling transmission lines, stringing lines, and winch lines.

RightRope’s signature design is a white rope with navy blue, pacific blue and grey tracers woven into the rope. Our pulling ropes are made using continuous filament yarns from end-to-end. We manufacture these heavy duty ropes to exceed Greenlee pulling rope specifications and have the highest breaking strengths in the industry. We partner with energy distribution and underground utility contractors to provide these ropes for power lines and telecommunication cable installations. Our pulling ropes offer excellent abrasion resistance, UV resistance, and superior resistance to most chemicals. They are torque-free with very low stretch, have a low coefficient of friction, and are the highest strength available.

Important Safety Tip

We recommend a 4:1 safety factor to determine the rated capacity or working load limit of a cable pulling rope. If you have a high force cable puller that is rated for a maximum force of 4,000 pounds, then you would need a rope with a minimum 16,000 pound tensile strength. Please reference our specifications tab for the working load limits of each diameter rope.

Our ropes come shrink-wrapped on a heavy-duty, wooden, spool / reel that can be used over and over. Each end of your rope will come with a professionally spliced and stitched eye. Our double braid cable pulling ropes are available in any diameter and length, including custom lengths. Contact us for a quote on custom lengths if needed.

You can purchase some poly twine as part of your wire pulling kit. You can blow the wire pulling twine through your conduit and use it to pull your electrical cable pulling rope through. If you have a very heavy rope or very long pull, consider using one of our pull tapes to pull your rope through.

Reviews

Specs

Physical Properties

Strength

Physical Percentage: 70%

Stretch

Physical Percentage: 20%

Durability

Physical Percentage: 80%

Degradation Resistance

Abrasion Resistance

Resistance Percentage: 80%

Rot Resistance

Resistance Percentage: 90%

Sunlight / UV Resistance

Resistance Percentage: 90%

Petroleum Resistance

Resistance Percentage: 90%

Mold / Mildew Resistance

Resistance Percentage: 90%

Rope Strength

Diameter Weight (Lbs / 100 Ft) Breaking Strength Safe Working Load Limit (SWLL)
3/8 4.5 5000 1250
7/16 6.1 7500 1875
1/2 8.1 10250 2562.5
9/16 10 16150 4037.5
5/8 13 18000 4500
3/4 18 26000 6500
7/8 25 32000 8000
1 32 42000 10500
